High resolution LCD ，eddy current flaw detector，can detect square ,oval ,flat shaped matials

Name: High resolution LCD eddy current flaw detectorcan detect square oval flat shaped matials
Brand: Desisen
Price: 1 USD

Brand Name : Desisen

Model Number : DMD-O

Certification : CE,Rosh

Place of Origin : China

MOQ : 1

Price : Negotiate

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100pieces/month

Delivery Time : 5-8days

Packaging Details : wooden

Product name : eddy current flaw detector

Display : High-resolution LCD

Detection object : Square, oval, flat and other special-shaped materials

Frequency Range : 64 Hz～2 MHz

Gain range : 0-90dbcontinuously adjustable, step: 0.5dB

Phase rotation : 0 ~ 360° continuously adjustable, step: 1 Deg

Detection speed : 150 m/min

Operating Temperature : Tippically from -15°C to + 55°C

Storage temperature : Tippically from -20℃ to +50℃

Operating voltage : AC220±10V

Gain ratio : (Y/X) 0.1 ~ 10.0

Relative humidity : Not more than 85%

Contact Now

High resolution LCD ,eddy current flaw detector,can detect square ,oval ,flat shaped matials

Discriptions

DMD-O eddy current flaw detectors are nondestructive testing (NDT) instruments used to identify flaws, cracks, or other material defects in conductive materials. They operate based on the principles of electromagnetic induction and are widely used in industries such as aerospace, manufacturing, and maintenance.
DMD-O portable eddy current flaw detector adopt the most advanced digital electronic technology, eddy current technology and microprocessor technology, real effectively detect defects in metal components, to distinguish the type of alloy and heat treatment, and thickness variations, etc. FET-9HP intelligent digital Portable eddy current flaw detector is a small intelligent digital eddy current inspection instrument, adjustable phase, gain, test frequency, small size, lightweight, portable, built-in rechargeable battery can be no power supply on-site testing. The interference signal can be effectively suppressed and the operation is simple and convenient, and the frequency, the gain and the phase of the instrument are preset by the professional personnel. In the test, the operator at any time to detection the corresponding parameters of the detection can be carried out. The operator does not require special training for a long time, who can carry out work.
DMD-O eddy current flaw detector uses high-resolution LCD display to display the measurement results, complete and compact industrial integrated design method, to ensure the reliability and robustness of the instrument.DMD-O eddy current flaw detector is suitable for on-line flaw detection, thickness measurement and sorting of various metal pipes, rods, wires and other metal parts.

Specifications

DMD-O eddy current flaw detectors

Frequency Range	64 Hz～2 MHz
Gain range	0-90dbcontinuously adjustable, step: 0.5dB
Phase rotation	0 ~ 360° continuously adjustable, step: 1 Deg
Detection speed	150 m/min
Display	High-resolution LCD
Gain ratio	(Y/X) 0.1 ~ 10.0
Operating voltage	AC220±10 v
Operating Temperature	Tippically from -15°C to + 55°C
Storage temperature	Tippically from -20℃ to +60℃
Relative humidity	Not more than 85%
Display	High-resolution LCD
Detection object	Square, oval, flat and other special-shaped materials

Other descriptions

1,DMD-O eddy current flaw detectors is suitable for mechanical manufacturers of raw materials into the warehouse inspection.
2,DMD-O eddy current flaw detectors can replace hydraulic test, online 100% detection, high speed and low cost.
3,DMD-O eddy current flaw detectorscan store a variety of test data, charts and other test results.
